IMPACT HYDRAULIC GRAB

Details & Specs

Impact Hydraulic Grab - Suits 1.5 to 2.0 Tonne Excavators

The heavy-duty Impact Hydraulic Grab is the most versatile for all grappling applications. Its unique, 5 Finger configuration allows ultimate flexibility and uses around worksites, demolition, farms or any project that requires pin point pick-up accuracy.

Due to the dimensions of this item, all deliveries will be shipped to the closest freight depot, or Commercial business with forklift facilities.

Please note, that any location with a house is considered a residential property, including farms and businesses.

Suits Excavators - 1.5 to 2.0 Tonne
Includes hydraulic hoses and fittings

Specifications

Brand: Impact Construction Equipment
Model: IHG200
Suited: 1.5 to 2.0 Tonne Excavators
Weight: 110kg
Width: 340mm
Height: 740mm
Opening: 720mm
Sizes Available: 1.5-2.0T, 2.5-3.5T, 4.5-6.0T, 8.0-10.0T, 12.0-15.0T, 20.0-24.0T, 30.0-35.0T
Pick ups available:

Pins: 30mm l Pin Centres: 105mm l Between the Ears: 105mm
Pins: 30mm l Pin Centres: 85mm l Between the Ears 99mm

SKU	IHG200
Brand	Impact Construction Equipment
Shipping Weight	110.0000kg
Shipping Width	0.340m
Shipping Height	0.740m
Unit Of Measure	ea
